Plantain Chips and Flour Processing Plant

GEM Foodtech is a globally recognised manufacturer of leading-edge plantain chips & flour processing plant machinery. Our robust plantain chips & flour processing machinery are designed to offer benchmark performance and constant reliability. Build to comply with international standards, our processing plants have gained significant popularity among Indian and international clients.

Our plantain processing equipment can prepare plantains chips and flour by washing, cutting, frying/drying, and performing other specific actions. We can guarantee premium quality plantain chips and plantain flour from our machines. Our plantain chips and flour processing plant is highly efficient and the plantain products meet the requirements of your clients.

Plantain Chips Production Line

Bubble Washer for Plantain

  • The Plantain washer also fitted a filtration tank to continuously filter and remove dirt from
  • The capacity for the washer is 500-5000 kg/hr.
Enquiry

Plantain Chips & flour Processing Machinery

Plantain Slicer

  • The MoC of the machine is SS304
  • The function of the machine is to slices plantain in 2/4/6 mm slices
  • The capacity of the machine is 500 kg/hr to 1500 kg/hr.
Plantain Chips & flour Processing Machinery

Continuous Belt Fryer for Plantain

  • Adjustable frying time according to product
  • The Cooking oil loop is equipped with pressure protection to avoid pump from dry running.
  • Standard emergency stop button can immediately stop the operation of the equipment.
  • The combustion chamber is equipped with thermal protection to prevent the equipment from over
  • Automatic lifting hood makes it easy to clean and
  • Automatic temperature control can freely adjust the temperature to the product that is being
Plantain Chips & flour Processing Machinery

Air Cooling & Oil Removing Machine

  • Oil is removed by blowing high velocity air onto the
  • The position of the blower is adjustable to ensure desired velocity of air.
  • The speed of the conveyor is adjustable through
  • All Contact parts are in Food Grade Stainless
  • Capacity of the machine is from 200 Kgs/Hr. to 2000 Kgs/Hr as per requirement.
Plantain Chips & flour Processing Machinery

Vibratory Deoiling Machine

  • The vibrating screen is used to remove the oil on the surface through vibration.
  • The vibration of the equipment can be adjusted by adjusting the weights on the vibratory motor.
  • It is made of stainless steel
  • Capacity is 200 Kgs/Hr. to 2000 Kgs/Hr.
  • Capacity of the machine is from 200 Kgs/Hr. to 2000 Kgs/Hr. as per requirement.
Plantain Chips & flour Processing Machinery

Plantain Syrup Coating Machine

  • Unique centrifugal coating action is ideal for products.
  • The base product supply hopper with pneumatically controlled slide gate delivers product to the PLC controlled weigh scale.
  • Solution is introduced to the high-speed spinning disc liquid applicator via a positive displacement pump.
  • Cycle times vary depending on product type and number of ingredients added.
  • Precise control of the batch size, and delivery of the liquid and powder, maintains consistency of the finished coated product.
Plantain Chips & flour Processing Machinery

Seasoning Drum

  • It is used for continuous even coating of flavour on
  • Drum Design will be Special profiles for tumbling of product with angle 60:30.
  • Leg Supports is in
  • Fabrication Standard will be Laser cut & CNC Bend, TIG welded & properly matched.
  • Finishing will be Matt, Gbb Blasted (Outside) & Polished (Inside) finish.

Plantain Flour Production Line

Plantain Chips & flour Processing Machinery

Bubble Washer for Plantain

  • The Plantain washer also fitted a filtration tank to continuously filter and remove dirt from the Plantain.
  • The capacity for the washer is 500-5000 kg/hr.
Plantain Chips & flour Processing Machinery

Plantain Grinder

  • Inbuilt pre-cutter.
  • Plantain Grinder Machine With high efficiency.
  • Highly productive and precise product sizes.
  • Low power requirements.
  • Value for money.
  • Highly durable machine.
Plantain Chips & flour Processing Machinery

Plantain Belt Dryer

  • Drying temperature adjustable
  • Plantain contacted parts and outer plate are SS304 constructed.
  • Heating Media: Burner (fuel can be gas LPG or NG or diesel upon choice)
  • Has drying temperature and drying time display
  • Total 5 layer, SS mesh belt
  • Product traveling speed adjustable (control drying time)
  • temperature: 130o C
  • Has insulation remain heat within chamber.
  • PLC with HMI (Optional).
Plantain Chips & flour Processing Machinery

Plantain Flour Mill

Automatic Plantain Flour Powder Grinder Machine is made of stainless steel SS304.

It is multi-function, which can be used in the foodstuff area, medicine area and chemical area powder grinding.

  • Input Capacity : 200-250 Kgs/Hr.
  • Material : 304 Stainless Steel
  • power(KW) : 7.5
  • Fineness (mesh) : 10-120
